Applicatioin
Neoprene rubber sheet widely used as gasket sheet material.
Technical Data – Commercial Grade
Item | Specific Gravity |
Hardness |
Tensile Strength |
Elongation at break |
Working Temp. |
---|---|---|---|---|---|
HK36516 | 1.6g/cm³ | 65±5 ShoreA | 3MPA | 180% | -20 ~ +70°C |
HK36515 | 1.5g/cm³ | 65±5 ShoreA | 4MPA | 200% | -20 ~ +70°C |
HK35515 | 1.5g/cm³ | 55±5 ShoreA | 4MPA | 200% | -20 ~ +70°C |
Technical Data – High Grade
Item | Specific Gravity |
Hardness |
Tensile Strength |
Elongation at break |
Working Temp. |
---|---|---|---|---|---|
HK36516P | 1.6g/cm³ | 65±5 ShoreA | 5MPA | 250% | -20 ~ +70°C |
Specification
Thickness | Width | Length | Color | Insertion | Surface |
---|---|---|---|---|---|
1-50mm | 1/1.2/1.4m | 5-20m | Black, Red, Green, Etc. | 0Ply, 1Ply, 2Ply, 3Ply | Smooth/Fabric |
